PTM Drum and Wheelchair Platforms: PTM 500 [AE402]

PTM 500 [AE402]
  • PTM 500 [AE402] 0

Key Specifications

Capacity
500kg
Readability
0.1kg
Repeatability
0.1kg
Pan size
760x580mm

How to get your PTM 500 [AE402]

Contact us to receive a quote or to find your local dealer

Register your PTM 500 [AE402]

Click the link below for the warranty registration form.

The PTM wheelchair scale features a low-profile base and easy-access ramps on both sides, offering smooth transitions from the floor to the platform.

Suitable for use in warehouses or medical facilities, the PTM wheelchair scale is ideal for checking the weight of wheelchair occupants and patient with limited accessibility, as wel as barrels and drums, or loaded dollies. The PTM features a stainless steel diamond plate surface that provides good grip and a solid, steady weighing area. Handles and wheels enable easy portability in a warehouse, doctors surgery or other medical environments.

The PTM is available with the GK indicator or AE 402 indicator, offering a range of features and functions. The GK indicator allows a numeric tare value to be entered, while the AE402 is IP66 rated for dusty and wet environments.

PTM 500 [AE402] Specifications

Capacity
500kg
Readability
0.1kg
Repeatability
0.1kg
Weighing Units
kg, lb, lb:oz, oz, N
Calibration
External calibration
Stabilization Time
2.0
Pan Size
760x580mm
Linearity
0.2kg
Power Supply
12VDC 50/60Hz 800mA adapter / Internal rechargeable battery
Construction
Mild steel base
Interface
RS-232
Operating Temperature
-10° to 40°C
Net Weight
35.5kg
Overall Dimensions
1020x803x75mm (wxdxh)
Approvals
N/A
Display Digit Height
40mm
Battery Life (Hours)
90.0

View alternative models

Features and Benefits

Hardware

  • Adjustable levelling feet help optimise setup
  • Built-in ramps on each side enable easy access
  • Chequered plate surface for added grip
  • Heavy-duty rubber feet ensure stability of unit
  • Integrated wheels permit easy movement
  • Three-meter load cell cable
  • Rugged construction stands up to industrial use
  • Ramps allow easy access for wheelchair use

Downloads

Applications

  • CheckweighingCheckweighing
  • Dynamic / animal weighingDynamic / animal weighing
  • Percentage weighingPercentage weighing
  • WeighingWeighing

Accessories

Here is a list of our available related products and suitable accessories:
