PT Stainless Steel Platforms with AE 403: PT 315S [AE403]

PT 315S [AE403]
  • PT 315S [AE403] 1
  • PT 315S [AE403] 0

Key Specifications

Capacity
3000kg
Readability
0.5kg
Repeatability
1kg
Pan size
1500x1500mm
Approvals
N/A

How to get your PT 315S [AE403]

Contact us to receive a quote or to find your local dealer

Register your PT 315S [AE403]

Click the link below for the warranty registration form.

Ideal for weighing food products, chemicals, pharmaceuticals or mining materials, the PT stainless steel platform features an IP66 rating for protection against water and dust. An easy-to-clean grade 304 stainless steel pan can tolerate frequent washing, while the sleek brushed surface helps prevent the accumulation of food and dirt particles. The reinforced frame beneath the platform provides strength and support. The PT stainless steel platform can be paired with an Adam indicator to provide the features and functions needed for any weighing task.

This platform scale comes with our AE403 weighing scale indicator. The AE403 is constructed from sturdy, IP67-rated stainless steel that makes the device ideal for use in food processing areas, dockyards and warehouses.

PT 315S [AE403] Specifications

Capacity
3000kg
Readability
0.5kg
Repeatability
1kg
Weighing Units
g, kg, lb, lb:oz, oz, N
Calibration
External calibration
Stabilization Time
2.0
Pan Size
1500x1500mm
Linearity
1kg
Power Supply
12VDC 50/60Hz 800mA adapter / Internal rechargeable battery
Construction
Stainless steel
Interface
RS-232
Operating Temperature
-10° to 40°C
Net Weight
111kg
Overall Dimensions
1500x1500x110mm (wxdxh)
Approvals
N/A
Display Digit Height
40mm
Battery Life (Hours)
90.0

View alternative models

Features and Benefits

Approval

  • IP66-rated for protection against water and dust

Hardware

  • Rugged stainless steel construction for ultimate durability
  • Approximately three-meter/10-foot shielded cable
  • Can be used with any Adam indicators
  • Heavy-duty rubber feet ensure stability of unit
