Nimbus® Analytical Balances

Nimbus® Analytical Balances
  • Nimbus® Analytical Balances 1
  • Nimbus® Analytical Balances 360 - 1#1
  • Nimbus® Analytical Balances 2
  • Nimbus® Analytical Balances 0

Innovative design enables a compact footprint, so it occupies minimal space but retains a high level of performance. The Nimbus base is formed from a single piece of extruded aluminum, a material that provides superior temperature regulation. The single-piece construction offers greater stability, producing highly repeatable results. The weighing sensor in the Nimbus is crafted from a single block, and contains fewer parts than a traditional force motor balance. This optimized internal mechanism is fabricated using hardened materials, helping the Nimbus tolerate rigorous laboratory use. Efficiency in the mechanics, plus improved processing power of the electronics, leads to excellent performance.

Key Specifications

Capacity
80g to 250g
Readability
0.0001g
View all models

Features

  • Backlit displayBacklit display
  • Below balance weighingBelow balance weighing
  • DateDate
  • External calibrationExternal calibration
  • GLP/ISO Print ReportsGLP/ISO Print Reports
  • RS-232RS-232
  • Security lock downSecurity lock down
  • Tare FunctionTare Function
  • TimeTime
  • USBUSB

Applications

  • Density determinationDensity determination
  • Dynamic / animal weighingDynamic / animal weighing
  • Parts countingParts counting
  • Percentage weighingPercentage weighing
  • WeighingWeighing

Features and Benefits

Hardware

  • Colour-coded keys facilitate quick recognition of the most frequently used buttons
  • Level indicator and adjustable feet ensure proper balance setup for optimum weighing results
  • Robust metal housing protects internal components in harsh environments
  • Sealed keypad protects against dirt and spills
  • USB and RS-232 interfaces provide speedy communication with computers and printers
  • Large, grade 304 stainless steel pan allows easy cleaning
  • Vivid, backlit LCD easily visible in any lighting conditions
  • Lockdown device to secure balance

Software

  • External calibration allows for verification and adjustment with weights
  • Printouts include date and time for data tracking within Good Laboratory Practices (GLP) guidelines
  • Selectable digital filtering helps minimise effects of vibration and disturbances
  • Multilingual display allows use in many different countries

Display

  • Vivid, backlit LCD easily visible in any lighting conditions

Power

  • AC adapter included

Models

Model Capacity Readability Pan Size Approvals Request a Quote
Picture of NBL 84eNBL 84e 80g 0.0001g 90mm ø   Request a Quote
Picture of NBL 84iNBL 84i 80g 0.0001g 90mm ø   Request a Quote
Picture of NBL 124eNBL 124e 120g 0.0001g 90mm ø   Request a Quote
Picture of NBL 124iNBL 124i 120g 0.0001g 90mm ø   Request a Quote
Picture of NBL 164eNBL 164e 160g 0.0001g 90mm ø   Request a Quote
Picture of NBL 164iNBL 164i 160g 0.0001g 90mm ø   Request a Quote
Picture of NBL 214eNBL 214e 210g 0.0001g 90mm ø   Request a Quote
Picture of NBL 214iNBL 214i 210g 0.0001g 90mm ø   Request a Quote
Picture of NBL 254eNBL 254e 250g 0.0001g 90mm ø   Request a Quote
Picture of NBL 254iNBL 254i 250g 0.0001g 90mm ø   Request a Quote

Videos

Downloads

Manuals

Datasheets and Brochures

Accessories

Here is a list of our available related products and suitable accessories:

Product Image Product Name Item Number Link
Anti-vibration table Anti-vibration table 104008036 View
ATP thermal printer paper ATP thermal printer paper 3126011263 View
ATP thermal printer paper (pack of 10) ATP thermal printer paper (pack of 10) 3126011281 View
ATP thermal printer ATP thermal printer 1120011156 View
Density kit for 0.0001g Density kit for 0.0001g 1060012713 View
AdamDU Data Collection Program AdamDU Data Collection Program 600002028 View
RS-232 cable M-F RS-232 cable M-F 3014011014 View
USB cable USB cable 3074010267 View
Dust cover for 0.1mg balances Dust cover for 0.1mg balances 3012313007 View
Security cable Security cable 3014013041 View
Weigh-below hook Weigh-below hook 3021210953 View
Calibration certificate Calibration certificate 700660290 View
