Nimbus® Precision Balances: NBL 4201e

NBL 4201e
  • NBL 4201e 1
  • NBL 4201e 2
  • NBL 4201e 0

Key Specifications

Capacity
4200g
Readability
0.1g
Repeatability
0.2g
Pan size
160mm ø
View more specifications

How to get your NBL 4201e

Contact us to receive a quote or to find your local dealer

Send Request

Register your NBL 4201e

Click the link below for the warranty registration form.

Register

Durable and reliable, Nimbus precision balances deliver a full breadth of readabilities ranging from 1mg to 0.1g. Innovative design enables a compact footprint, so it occupies minimal space but retains a high level of performance. The single-piece construction offers greater stability, producing highly repeatable results. The weighing sensor in the Nimbus is crafted from a single block, and contains fewer parts than a traditional force motor balance. This optimised internal mechanism is fabricated using hardened materials, helping the Nimbus tolerate rigorous laboratory use. Efficiency in the mechanics, plus improved processing power of the electronics, leads to excellent performance.

NBL 4201e Specifications

Capacity
4200g
Readability
0.1g
Repeatability
0.2g
Weighing Units
g, kg, ct, GN, N, lb, oz, ozt, dwt, custom unit
Calibration
External calibration
Stabilization Time
3.0
Pan Size
160mm ø
Linearity
0.2g
Power Supply
18VDC 50/60Hz 830mA adapter
Construction
Extruded aluminum base with a die-cast aluminum case
Interface
RS-232, USB
Operating Temperature
15° to 35°C
Net Weight
3.1kg
Overall Dimensions
220x310x90mm (wxdxh)
Electrical Safety Mark
CE, cUL
Approvals
N/A
Display Digit Height
20mm

View alternative models

Features and Benefits

Hardware

  • Colour-coded keys facilitate quick recognition of the most frequently used buttons
  • Level indicator and adjustable feet ensure proper balance setup for optimum weighing results
  • Removable draught shield on models with 0.001g readability helps to reduce errors caused by air currents
  • Robust metal housing protects internal components in harsh environments
  • Sealed keypad protects against dirt and spills
  • USB and RS-232 interfaces provide speedy communication with computers and printers
  • Large, grade 304 stainless steel pan allows easy cleaning
  • Vivid, backlit LCD easily visible in any lighting conditions
  • Lockdown device to secure balance

Software

  • External calibration allows for verification and adjustment with weights
  • Printouts include date and time for data tracking within Good Laboratory Practices (GLP) guidelines
  • Selectable digital filtering helps minimise effects of vibration and disturbances
  • Zero-tracking feature ensures display returns to zero reading
  • Multilingual display allows use in many different countries

Display

  • Vivid, backlit LCD easily visible in any lighting conditions

Power

  • AC adapter included

Downloads

Manuals

Datasheets

Applications

  • Density determinationDensity determination
  • Dynamic / animal weighingDynamic / animal weighing
  • Parts countingParts counting
  • Percentage weighingPercentage weighing
  • WeighingWeighing

Technical Highlights

  • Backlit displayBacklit display
  • Below balance weighingBelow balance weighing
  • DateDate
  • External calibrationExternal calibration
  • GLP/ISO Print ReportsGLP/ISO Print Reports
  • RS-232RS-232
  • Security lock downSecurity lock down
  • Tare FunctionTare Function
  • TimeTime
  • USBUSB

Videos

Accessories

Here is a list of our available related products and suitable accessories:

Product Image Product Name Item Number Link
Anti-vibration table Anti-vibration table 104008036 View
ATP thermal printer paper ATP thermal printer paper 3126011263 View
ATP thermal printer paper (pack of 10) ATP thermal printer paper (pack of 10) 3126011281 View
ATP thermal printer ATP thermal printer 1120011156 View
Density kit for 0.001g Density kit for 0.001g 1060012714 View
Adam DU Data Collection Program Adam DU Data Collection Program 600002028 View
RS-232 cable M-F RS-232 cable M-F 3014011014 View
Rechargeable Battery Pack Rechargeable Battery Pack 2010012712 View
USB cable USB cable 3074010267 View
Dust cover for 0.01g and 0.001g balances Dust cover for 0.01g and 0.001g balances 3012313008 View
In-use wet cover for 120mm ø and 160mm ø pan In-use wet cover for 120mm ø and 160mm ø pan 3012013010 View
In-use wet cover for 400x300mm pan In-use wet cover for 400x300mm pan 3012013012 View
Security cable Security cable 3014013041 View
Weigh-below hook Weigh-below hook 3021210953 View
Weigh-below hook for 400x300mm pan Weigh-below hook for 400x300mm pan 302126013 View
Calibration certificate Calibration certificate 700660290 View
