Latitude Compact Bench Scales: LBX 30

LBX 30
  • LBX 30 0
  • LBX 30 2
  • LBX 30 1

Key Specifications

Capacity
30kg
Readability
5g
Repeatability
5g
Pan size
245x180mm

How to get your LBX 30

Contact us to receive a quote or to find your local dealer

Register your LBX 30

Click the link below for the warranty registration form.

Latitude compact bench scales deliver an excellent value for weighing, checkweighing, percentage weighing, and counting. With easy operation, Latitude is ideal for production, warehouse, or field use, as it is powered by the included AC adapter or internal rechargeable battery. The battery operates for 240 hours, so there are no worries about losing power. For added flexibility and convenience, Latitude can be charged using any USB power source, such as the USB connection in a vehicle or external USB power banks.

LBX 30 Specifications

Capacity
30kg
Readability
5g
Repeatability
5g
Weighing Units
g, kg, lb, lb:oz, oz
Calibration
External calibration
Stabilization Time
1.0
Pan Size
245x180mm
Linearity
10g
Power Supply
5VDC 1A adapter / Internal rechargeable battery
Construction
ABS plastic
Operating Temperature
0° to 40°C
Net Weight
2.5kg
Overall Dimensions
255x290x105mm (wxdxh)
Approvals
N/A
Display Digit Height
24mm
Battery Life (Hours)
240.0

View alternative models

Features and Benefits

Hardware

  • Overload protection helps prevent damage to internal components
  • Rugged construction stands up to industrial use
  • Sealed keypad protects against dirt and spills
  • Simple key operation allows for easy set up and operation
  • Large, grade 304 stainless steel pan allows easy cleaning
  • Adjustable levelling feet help optimise setup

Software

  • External calibration allows for verification and adjustment with weights
  • Checkweighing with audible alarm
  • Hold function freezes the displayed weight, allowing time to elapse without losing the result
  • Parts counting with preset sample sizes

Display

  • Vivid, backlit LCD easily visible in any lighting conditions
  • Checkweighing LEDs clearly show under, over and acceptable limits

Power

  • Rechargeable battery included for operation almost anywhere
  • Programmable auto power-off to save energy
  • Battery level is clearly displayed to show the user when the scale needs to be recharged
  • Operates with a low voltage USB input providing flexibility for powering the device

Downloads

Applications

  • CheckweighingCheckweighing
  • Parts countingParts counting
  • Percentage weighingPercentage weighing
  • WeighingWeighing

Technical Highlights

  • Backlit displayBacklit display
  • Internal rechargeable batteryInternal rechargeable battery
  • External calibrationExternal calibration
  • Multiple weighing unitsMultiple weighing units
  • Tare FunctionTare Function
