Latitude Compact Bench Scales: LBX 12

Key Specifications
- Capacity
- 12kg
- Readability
- 2g
- Repeatability
- 2g
- Pan size
- 245x180mm
Latitude compact bench scales deliver an excellent value for weighing, checkweighing, percentage weighing, and counting. With easy operation, Latitude is ideal for production, warehouse, or field use, as it is powered by the included AC adapter or internal rechargeable battery. The battery operates for 240 hours, so there are no worries about losing power. For added flexibility and convenience, Latitude can be charged using any USB power source, such as the USB connection in a vehicle or external USB power banks.
LBX 12 Specifications
- Capacity
- 12kg
- Readability
- 2g
- Repeatability
- 2g
- Weighing Units
- g, kg, lb, lb:oz, oz
- Calibration
- External calibration
- Stabilization Time
- 1.0
- Pan Size
- 245x180mm
- Linearity
- 4g
- Power Supply
- 5VDC 1A adapter / Internal rechargeable battery
- Construction
- ABS plastic
- Operating Temperature
- 0° to 40°C
- Net Weight
- 2.5kg
- Overall Dimensions
- 255x290x105mm (wxdxh)
- Approvals
- N/A
- Display Digit Height
- 24mm
- Battery Life (Hours)
- 240.0
Features and Benefits
Hardware
- Overload protection helps prevent damage to internal components
- Rugged construction stands up to industrial use
- Sealed keypad protects against dirt and spills
- Simple key operation allows for easy set up and operation
- Large, grade 304 stainless steel pan allows easy cleaning
- Adjustable levelling feet help optimise setup
Software
- External calibration allows for verification and adjustment with weights
- Checkweighing with audible alarm
- Hold function freezes the displayed weight, allowing time to elapse without losing the result
- Parts counting with preset sample sizes
Display
- Vivid, backlit LCD easily visible in any lighting conditions
- Checkweighing LEDs clearly show under, over and acceptable limits
Power
- Rechargeable battery included for operation almost anywhere
- Programmable auto power-off to save energy
- Battery level is clearly displayed to show the user when the scale needs to be recharged
- Operates with a low voltage USB input providing flexibility for powering the device
Downloads
Manuals
- Manual (English): Latitude Compact Bench Scales - LBX_UM_EN.pdf
- Manual (Français): Latitude Compact Bench Scales - LBX_UM_FR.pdf
- Manual (Deutsche): Latitude Compact Bench Scales - LBX_UM_DE.pdf
Datasheets
- Datasheet (English): Latitude Compact Bench Scales - LBX-DS-A4-EN.pdf
- Datasheet (Français): Latitude Compact Bench Scales - LBX-DS-A4-FR.pdf
- Datasheet (Deutsche): Latitude Compact Bench Scales - LBX-DS-A4-DE.pdf
- Datasheet (Español): Latitude Compact Bench Scales - LBX-DS-A4-SP.pdf
- Datasheet (中文): Latitude Compact Bench Scales - LBX-DS-A4-CN.pdf
- Datasheet (Italiano): Latitude Compact Bench Scales - LBX-DS-A4-IT.pdf
Applications
Checkweighing
Parts counting
Percentage weighing
Weighing
Technical Highlights
Backlit display
Internal rechargeable battery
External calibration
Multiple weighing units
Tare Function
