Equinox analytical balances deliver remarkable precision to labs that perform highly detailed testing. The Equinox is ideal for research and quality assurance facilities; science education; precision counting; and production and manufacturing applications needing exceptionally precise results. Eight analytical models offer capacities from 120g to 510g and 0.1mg readability. A colour touch screen display provides intuitive operation, with icon-driven menus and readily accessible applications and functions. The five-inch screen is generously sized, offering 800 X 480 pixel resolution for excellent visibility.

Key Specifications

Capacity
120g to 510g
Readability
0.01mg/ 0.1mg to 0.0001g
View all models

Features

  • Backlit displayBacklit display
  • DateDate
  • External calibrationExternal calibration
  • GLP/ISO Print ReportsGLP/ISO Print Reports
  • Internal calibrationInternal calibration
  • Multiple weighing unitsMultiple weighing units
  • RS-232RS-232
  • Security lock downSecurity lock down
  • Tare FunctionTare Function
  • TimeTime
  • USBUSB

Features and Benefits

Hardware

  • Level indicator and adjustable feet ensure proper balance setup for optimum weighing results
  • Security slot for optional Kensington-type lock and cable to help prevent theft
  • Large, grade 304 stainless steel pan allows easy cleaning
  • RS-232 interface is available to provide speedy connection to computers and printers
  • USB host for memory card

Software

  • Built-in memory for storing products and settings
  • External calibration allows for verification and adjustment with weights
  • Selectable digital filtering helps minimise effects of vibration and disturbances
  • Security password control prevents unauthorised access
  • Printouts include date and time for data tracking within Good Laboratory Practices (GLP) guidelines
  • Preset tare function speeds the process of repetitive weighing
  • Parts counting with freely selectable sample sizes
  • Multilingual display allows use in many different countries
  • Memory accumulation totals results
  • Checkweighing with audible alarm

Display

  • Large, responsive 5’’ 800x480 pixel touch-screen display

Power

  • AC adapter included

Models

Model Capacity Readability Pan Size Approvals Request a Quote
Picture of EAB 125iEAB 125i 62g / 120g 0.01mg/ 0.1mg 80mm ø   Request a Quote
Picture of EAB 225iEAB 225i 82g / 220g 0.01mg/ 0.1mg 80mm ø   Request a Quote
Picture of EAB 124eEAB 124e 120g 0.0001g 80mm ø   Request a Quote
Picture of EAB 224eEAB 224e 220g 0.0001g 80mm ø   Request a Quote
Picture of EAB 314eEAB 314e 310g 0.0001g 80mm ø   Request a Quote
Picture of EAB 124iEAB 124i 120g 0.0001g 80mm ø   Request a Quote
Picture of EAB 224iEAB 224i 220g 0.0001g 80mm ø   Request a Quote
Picture of EAB 314iEAB 314i 310g 0.0001g 80mm ø   Request a Quote
Picture of EAB 414iEAB 414i 410g 0.0001g 80mm ø   Request a Quote
Picture of EAB 514iEAB 514i 510g 0.0001g 80mm ø   Request a Quote
