Eclipse® Analytical Balances

Eclipse® Analytical Balances
  • Eclipse® Analytical Balances 1
  • Eclipse® Analytical Balances 360 - 1#1
  • Eclipse® Analytical Balances 2
  • Eclipse® Analytical Balances 0

With a capacitive touch keypad and one of the largest LCD readouts in the industry, Eclipse analytical balances provide a unique weighing experience for lab professionals. An innovative design results in a compact footprint that occupies minimal space on the lab bench yet offers a wide array of features.

Single-piece construction allows greater stability, enabling highly repeatable results. Containing fewer parts than a traditional force motor balance, the weighing sensor features an optimised internal mechanism, helping the Eclipse tolerate rigorous laboratory use.

Key Specifications

Capacity
100g to 250g
Readability
0.0001g
View all models

Features

  • Backlit displayBacklit display
  • Below balance weighingBelow balance weighing
  • DateDate
  • External calibrationExternal calibration
  • GLP/ISO Print ReportsGLP/ISO Print Reports
  • Internal calibrationInternal calibration
  • Multiple weighing unitsMultiple weighing units
  • RS-232RS-232
  • Security lock downSecurity lock down
  • Tare FunctionTare Function
  • TimeTime

Applications

  • AccumulationAccumulation
  • Check countingCheck counting
  • CheckweighingCheckweighing
  • Density determinationDensity determination
  • Dynamic / animal weighingDynamic / animal weighing
  • Parts countingParts counting
  • Percentage weighingPercentage weighing
  • WeighingWeighing

Features and Benefits

Hardware

  • Large, grade 304 stainless steel pan allows easy cleaning
  • Overload protection helps prevent damage to internal components
  • Robust metal housing protects internal components in harsh environments
  • Sealed keypad protects against dirt and spills
  • USB and RS-232 interfaces provide speedy communication with computers and printers
  • Level indicator and adjustable feet ensure proper balance setup for optimum weighing results
  • The illuminated capacitive touch keypad provides responsive operation, and its durable, smooth surface can be easily wiped down

Software

  • External calibration allows for verification and adjustment with weights
  • Multilingual display allows use in many different countries
  • Printouts include date and time for data tracking within Good Laboratory Practices (GLP) guidelines
  • Security password control prevents unauthorised access
  • Selectable digital filtering helps minimise effects of vibration and disturbances

Display

  • Vivid, backlit LCD easily visible in any lighting conditions
  • Capacity tracker built into display for easily monitoring possible overloads
  • Programmable backlight can be set to "always on," "always off" or "light only when weighing"

Power

  • AC adapter included

Models

Model Capacity Readability Pan Size Approvals Request a Quote
Picture of EBL 104eEBL 104e 100g 0.0001g 90mm ø   Request a Quote
Picture of EBL 104iEBL 104i 100g 0.0001g 90mm ø   Request a Quote
Picture of EBL 164eEBL 164e 160g 0.0001g 90mm ø   Request a Quote
Picture of EBL 164iEBL 164i 160g 0.0001g 90mm ø   Request a Quote
Picture of EBL 214eEBL 214e 210g 0.0001g 90mm ø   Request a Quote
Picture of EBL 214iEBL 214i 210g 0.0001g 90mm ø   Request a Quote
Picture of EBL 254eEBL 254e 250g 0.0001g 90mm ø   Request a Quote
Picture of EBL 254iEBL 254i 250g 0.0001g 90mm ø   Request a Quote

Videos

Downloads

Manuals

Datasheets and Brochures

Accessories

Here is a list of our available related products and suitable accessories:

Product Image Product Name Item Number Link
Anti-vibration table Anti-vibration table 104008036 View
ATP thermal printer paper ATP thermal printer paper 3126011263 View
ATP thermal printer paper (pack of 10) ATP thermal printer paper (pack of 10) 3126011281 View
ATP thermal printer ATP thermal printer 1120011156 View
Density kit for 0.0001g Density kit for 0.0001g 1060012713 View
AdamDU Data Collection Program AdamDU Data Collection Program 600002028 View
RS-232 cable M-F RS-232 cable M-F 3014011014 View
USB cable USB cable 3074010267 View
Dust cover for 0.1mg balances Dust cover for 0.1mg balances 3012313007 View
Security cable Security cable 3014013041 View
Weigh-below hook Weigh-below hook 3021210953 View
Calibration certificate Calibration certificate 700660290 View
