CB Compact Balances: CB 501

CB 501
  • CB 501 1
  • CB 501 2
  • CB 501 0

Key Specifications

Capacity
500g
Readability
0.1g
Repeatability
0.1g
Pan size
130mm ø

How to get your CB 501

Contact us to receive a quote or to find your local dealer

Register your CB 501

Click the link below for the warranty registration form.

CB balances can manage most small tasks, such as measuring compounds in chemistry classes, portioning at food service establishments, or weighing small animals. Compact and portable, the CB transports easily to the field, or from bench to bench in a science classroom. The CB is powered by battery or an optional AC adapter.

A sealed keypad and one-piece housing make the CB simple to clean, and help protect internal components from dirt and spills. The grade 304 stainless steel pan can be wiped down quickly and accommodates either single items or bulk powders.

CB 501 Specifications

Capacity
500g
Readability
0.1g
Repeatability
0.1g
Weighing Units
g, lb, oz
Calibration
External calibration
Stabilization Time
2.0
Pan Size
130mm ø
Linearity
0.3g
Power Supply
2 x AA batteries / Optional 6VDC 200mA adapter
Construction
ABS plastic
Operating Temperature
0° to 40°C
Net Weight
0.4kg
Overall Dimensions
160x205x45mm (wxdxh)
Approvals
N/A
Display Digit Height
12mm
Battery Life (Hours)
6.0

View alternative models

Features and Benefits

Hardware

  • Large, grade 304 stainless steel pan allows easy cleaning
  • Lightweight design simplifies transport and portability
  • Sealed keypad protects against dirt and spills
  • Level indicator and adjustable feet ensure proper balance setup for optimum weighing results

Software

  • External calibration allows for verification and adjustment with weights
  • Simple operation allows quick startup and use with little or no training
  • Zero-tracking feature ensures display returns to zero reading

Display

  • Vivid, backlit LCD easily visible in any lighting conditions

Power

  • Low-battery indicator alerts users when batteries need replacement
  • Operates with AC adapter (not included) or batteries (included)

Downloads

Applications

  • WeighingWeighing

Technical Highlights

  • Backlit displayBacklit display
  • External battery powerExternal battery power
  • External calibrationExternal calibration
  • Tare FunctionTare Function
